| Ref |
No |
Description |
Price |
|
|
|
46481-AF
|
OWNER'S MANUAL
|
N/A
|
POA
|
|
001
|
63025-AF
|
TONGUE WELDMENT ASS`Y (REAR AF-63025
|
£208.81
|
Add
|
|
002
|
63155-AF
|
Tongue Weldment Ass'y. (Front)
|
£209.00
|
Add
|
|
003
|
23475-AF
|
HITCH BRACKET HD
|
£33.80
|
Add
|
|
004
|
24080-AF
|
Engine Base
|
N/A
|
POA
|
|
005
|
24078-AF
|
Brace, Housing
|
N/A
|
POA
|
|
006
|
63226-AF
|
Hose Hanger Bracket Ass'y. (Ref. item #16 on page 22.)
|
N/A
|
POA
|
|
007
|
43182-AF
|
Hex Bolt, 5/16" x 3/4" 43182
|
£4.31
|
Add
|
|
008
|
43063-AF
|
BOLT
|
£4.12
|
Add
|
|
009
|
43085-AF
|
Bolt, Hex 5/16-18 x 1-1/2"
|
£4.15
|
Add
|
|
010
|
43086-AF
|
Lock Washer, 5/16" 43086
|
£3.48
|
Add
|
|
011
|
712-0158
|
NUT, HEX CENTER LOCK, 5/16-18
|
£9.35
|
Add
|
|
012
|
63375-AF
|
Assembly, Hose Adapter (Nozzle) (Includes items 10 and 11))
|
N/A
|
POA
|
|
013
|
781-0635
|
Bracket, Switch (Actuator)
|
£37.62
|
Add
|
|
014
|
728-3001
|
RIVET, POP
|
£4.17
|
Add
|
|
015
|
681-0068A
|
Chute Assembly 681-0068
|
£168.21
|
Add
|
|
016
|
43012-AF
|
BOLT
|
£3.32
|
Add
|
|
017
|
712-0291
|
LOCK-NUT
|
£2.77
|
Add
|
|
018
|
63376-AF
|
ASS'Y., CHUTE, CHIPPER (UPPER)
|
N/A
|
POA
|
|
019
|
735-0249
|
Flap, Chute (Included in item 55)
|
£39.38
|
Add
|
|
020
|
781-0633
|
Strap, Flap (Included in item 55)
|
£9.50
|
Add
|
|
021
|
731-1617
|
TAMPER PLUG
|
£97.38
|
Add
|
|
022
|
7520155481
|
ENGINE, TECUMSEH 8 HP
|
N/A
|
POA
|
|
023
|
1522-1-AF
|
SCREW(10-12 X 5/8 SHEET METAL)
|
N/A
|
POA
|
|
024
|
24097-AF
|
DEFLECTOR, EXHAUST (NOT SHOWN)
|
N/A
|
POA
|
|
025
|
719-0330A
|
Adapter, Mounting
|
£76.48
|
Add
|
|
026
|
23488-AF
|
Axle, Wheel 1" Dia. 23488
|
£125.17
|
Add
|
|
027
|
63227-AF
|
Hose Hanger Rod Ass'y.
|
N/A
|
POA
|
|
028
|
46420-AF
|
Deflector w/ Elbow 46420
|
£333.97
|
Add
|
|
029
|
43792-AF
|
Hose 43792
|
£340.87
|
Add
|
|
030
|
43793-AF
|
Hose Clamp 43793
|
£18.87
|
Add
|
|
031
|
23834-AF
|
SIDE FRAME RIGHT AF-23834
|
£185.00
|
Add
|
|
032
|
23833-AF
|
PLATE-SIDE LH AF-23833
|
£185.00
|
Add
|
|
033
|
23835-AF
|
FRONT PANEL, CART EXTENSION AF-23835
|
£129.45
|
Add
|
|
034
|
23836-AF
|
Cross Brace 23836
|
£39.05
|
Add
|
|
035
|
63217-AF
|
Hard Top Assembly (Includes 24,25,26,27)
|
N/A
|
POA
|
|
036
|
46421-AF
|
TOP, POLY HARD
|
N/A
|
POA
|
|
037
|
23837-AF
|
BRACKET AF-23837
|
£48.66
|
Add
|
|
038
|
44792-AF
|
SCREEN AF-44792
|
£62.37
|
Add
|
|
039
|
43882-AF
|
Rivet, Stainless 43882
|
£4.85
|
Add
|
|
040
|
43910-AF
|
Washer, Flat #10 SAE 43910
|
£3.19
|
Add
|
|
041
|
23842-AF
|
Boot Mounting Strap 23842
|
£6.99
|
Add
|
|
042
|
46480-AF
|
Vinyl Boot (Hardtop) 46480
|
£80.05
|
Add
|
|
043
|
44790-AF
|
Poly Rear Door 44790
|
£314.16
|
Add
|
|
044
|
43790-AF
|
Tarp Strap, 25" 43790
|
£28.31
|
Add
|
|
045
|
44849-AF
|
"S" Hook, #32
|
N/A
|
POA
|
|
046
|
44850-AF
|
Strap, Tarp (Less Hooks)
|
N/A
|
POA
|
|
047
|
43884-AF
|
Hitch Pin 43884
|
£42.16
|
Add
|
|
048
|
23478-AF
|
CLIP-BODY AF-23478
|
£21.76
|
Add
|
|
049
|
23540-AF
|
Hitch Plate 23540
|
£13.72
|
Add
|
|
050
|
43012-AF
|
BOLT
|
£3.32
|
Add
|
|
051
|
43661-AF
|
HEX BOLT
|
£3.11
|
Add
|
|
052
|
43088-AF
|
FLAT WASHER
|
£3.11
|
Add
|
|
053
|
1509-090
|
NO LONGER AVAILABLE
|
N/A
|
POA
|
|
054
|
43178-AF
|
Hex Nut, 1/4-20 Thread
|
£3.37
|
Add
|
|
055
|
43177-AF
|
Washer, Lock 1/4" I.D.* 43177
|
£3.08
|
Add
|
|
056
|
23789-AF
|
Door Latch 23789
|
£7.06
|
Add
|
|
057
|
1543-69-AF
|
Washer, Nylon 1543-069
|
N/A
|
POA
|
|
058
|
23838-AF
|
Door Support 23838
|
£20.42
|
Add
|
|
059
|
44678-AF
|
Spacer (45-0351) 44678
|
£14.07
|
Add
|
|
060
|
43351-AF
|
Hex Bolt, 1/2-1 3 x 1-1/4" 43351
|
£5.18
|
Add
|
|
061
|
43262-AF
|
NUT 1/2-13 HEX LOCK
|
£6.20
|
Add
|
|
062
|
43352-AF
|
Flat Washer, 7/16" 43352
|
£3.48
|
Add
|
|
063
|
23655-AF
|
SPRING RETRAINER BRKT TRANS AF-23655
|
£8.54
|
Add
|
|
064
|
43796-AF
|
BOLT, HEX HD 1/4-20x2-3/4 GR 5 AF-43796
|
£4.05
|
Add
|
|
065
|
43343-AF
|
PIN COTTER
|
£4.20
|
Add
|
|
066
|
43574-AF
|
Hex Bolt, 3/8-16 x 3"
|
N/A
|
POA
|
|
067
|
736-0169
|
L. WASHER
|
£2.89
|
Add
|
|
068
|
43768-AF
|
BOLT,HEX 3/8-16x1-1/2 FULL THD AF-43768
|
£5.68
|
Add
|
|
069
|
43082-AF
|
HEX LOCK NUT
|
£4.12
|
Add
|
|
070
|
43087-AF
|
Hex Bolt, 3/8-16 x 1-1/4" Long 43087
|
£4.58
|
Add
|
|
071
|
43081-AF
|
FLAT WASHER
|
£3.49
|
Add
|
|
072
|
24098-AF
|
BRACKET, CHUTE REINFORCEMENT
|
N/A
|
POA
|
|
073
|
43830-AF
|
Adapter, Deck
|
£175.88
|
Add
|
|
074
|
23560-AF
|
Bracket, Deck Adapter
|
£47.89
|
Add
|
|
075
|
43080-AF
|
CARRIAGE BOLT
|
£3.49
|
Add
|
|
076
|
23825-AF
|
Mounting Strap
|
£4.15
|
Add
|
|
077
|
23826-AF
|
Bracket, Angle
|
£8.03
|
Add
|
|
078
|
23827-AF
|
Mounting Bracket
|
£11.33
|
Add
|
|
079
|
46703-AF
|
SCREW, SELF TAP 5/16-18 X 3/4" (SEE ALSO ITEM #5 PAGE 38)
|
N/A
|
POA
|
|
080
|
712-0421
|
KNOB
|
£6.43
|
Add
|
|
081
|
712-3010
|
NUT 5/16 x 18
|
£2.77
|
Add
|
|
082
|
736-0242
|
BELL WASHER
|
£3.72
|
Add
|
