| Ref |
No |
Description |
Price |
|
|
|
44374-AF
|
OWNER'S MANUAL
|
£8.75
|
Add
|
|
001
|
43903-AF
|
BRUSH, 32 IN SWEEP 43903
|
£23.03
|
Add
|
|
002
|
43890-AF
|
SPROCKET 43890
|
£26.12
|
Add
|
|
003
|
43889-AF
|
SPROCKET LH
|
£24.33
|
Add
|
|
004
|
43645-AF
|
SKIRT, PLASTIC (32") AF-43645
|
£20.39
|
Add
|
|
005
|
43720-AF
|
KNOB (RED)
|
£7.83
|
Add
|
|
006
|
23387-AF
|
STELLSCHIENE 23387
|
£11.38
|
Add
|
|
007
|
43979-AF
|
STRAP:LIFT HANDLE SUPPORT 43979
|
£21.81
|
Add
|
|
008
|
44309-AF
|
TUBE, HOPPER UPPER L.H.(32HI) AF-44309
|
£41.50
|
Add
|
|
009
|
44310-AF
|
TUBE, HOPPER UPPER R.H.(32HI) AF-44310
|
£44.04
|
Add
|
|
010
|
43930-AF
|
TUBE, HOPPER LOWER R.H. 32" AF-43930
|
£43.76
|
Add
|
|
011
|
43929-AF
|
LOWER HOPPER TUBE RIGHT AF-43929
|
£46.50
|
Add
|
|
012
|
44372-AF
|
BAG, HOPPER 32" HI SPEED A-F AF-44372
|
£346.47
|
Add
|
|
013
|
C-9M5732
|
Pop Rivet (OBSOLETE) (OBSOLETE) (OBSOLETE)
|
N/A
|
POA
|
|
014
|
43655-AF
|
SPANNRING.75" 43655
|
£4.15
|
Add
|
|
015
|
AF-1650-21
|
RETAINING RING
|
£2.61
|
Add
|
|
016
|
40001-AF
|
Washer, Shim 1-1/8" x .594" x .025" 44007-AF
|
£3.58
|
Add
|
|
017
|
43182-AF
|
Hex Bolt, 5/16" x 3/4" 43182
|
£4.31
|
Add
|
|
018
|
43407-AF
|
Bolt, Hex 3/8-16 x 3/4" Lg. * 43407
|
£3.91
|
Add
|
|
019
|
44008-AF
|
WASHER
|
£3.24
|
Add
|
|
020
|
44137-AF
|
Washer, Flat 1/2" I.D. 44137
|
£2.60
|
Add
|
|
021
|
43070-AF
|
Washer, 3/8"
|
£3.91
|
Add
|
|
022
|
714-0474
|
PIN (RED)
|
£3.20
|
Add
|
|
023
|
1038-AF
|
Nut, Nylock 3/8-24 Thread 1038
|
£3.48
|
Add
|
|
024
|
43661-AF
|
HEX BOLT
|
£3.11
|
Add
|
|
025
|
712-0291
|
LOCK-NUT
|
£2.77
|
Add
|
|
026
|
1095-AF
|
SL. SCR. #10-32 X 1/2 - 32" LAWN SWEEP
|
N/A
|
POA
|
|
027
|
43081-AF
|
FLAT WASHER
|
£3.49
|
Add
|
|
028
|
712-0158
|
NUT, HEX CENTER LOCK, 5/16-18
|
£9.35
|
Add
|
|
029
|
43080-AF
|
CARRIAGE BOLT
|
£3.49
|
Add
|
|
030
|
23400-AF
|
SPACER
|
£5.85
|
Add
|
|
031
|
44313-AF
|
BAG, WINDSCREEN 32 (HI BACK) AF-44313
|
£47.79
|
Add
|
|
032
|
HG-44232P
|
BALL BEARING
|
£70.26
|
Add
|
|
033
|
AF-1629-56
|
Retainer, Dust Cover 1629-56
|
£26.36
|
Add
|
|
034
|
62445-AF
|
HOUSING 62445
|
£191.99
|
Add
|
|
035
|
44321-AF
|
DUST COVER
|
£41.23
|
Add
|
|
036
|
43012-AF
|
BOLT
|
£3.32
|
Add
|
|
037
|
62501-AF
|
STOLLEINRICHTUNG ZUS. 62501
|
£61.83
|
Add
|
|
038
|
62489-AF
|
LAGERSCHALE AUßEN 62489
|
£42.99
|
Add
|
|
039
|
23723-AF
|
SHAFT, BRUSH (30") AF-23723
|
£97.02
|
Add
|
|
040
|
23580-AF
|
BRUSH RETAINER 42-0197
|
£9.24
|
Add
|
|
041
|
23581-AF
|
BRUSH RETAINER 42-0197
|
£5.45
|
Add
|
|
042
|
43985-AF
|
ASS'Y, WHT WHEEL W/10x2.5 TIRE 43985
|
N/A
|
POA
|
|
043
|
23345-AF
|
RUBBER STRIP AF-23345
|
£18.60
|
Add
|
|
044
|
43943-AF
|
Handle Grip 43943
|
£8.46
|
Add
|
|
045
|
43080-AF
|
CARRIAGE BOLT
|
£3.49
|
Add
|
|
046
|
2674-32-AF
|
Hub Cap 2674-32
|
N/A
|
POA
|
|
047
|
23014-AF
|
HITCH BRACKET
|
£31.67
|
Add
|
|
048
|
23595-AF
|
ARM, BAG MT LG 23595
|
£28.19
|
Add
|
|
049
|
23351-AF
|
STRAP, BAG FRAME 32 IN AF-23351
|
£25.88
|
Add
|
|
050
|
43938-AF
|
ROD, HOPPER SUPPORT
|
£12.19
|
Add
|
|
051
|
1671-1-AF
|
PAWL MOD 60 1671-1
|
£11.82
|
Add
|
|
052
|
43346-AF
|
Truss Head Bolt, #10- 32 x 5/8" 43346
|
£3.48
|
Add
|
|
053
|
43662-AF
|
Lock Nut, 10-32 43662
|
£3.73
|
Add
|
|
054
|
44322-AF
|
CHAIN SHIELD
|
£34.26
|
Add
|
|
055
|
712-0158
|
NUT, HEX CENTER LOCK, 5/16-18
|
£9.35
|
Add
|
|
056
|
43182-AF
|
Hex Bolt, 5/16" x 3/4" 43182
|
£4.31
|
Add
|
|
057
|
712-0291
|
LOCK-NUT
|
£2.77
|
Add
|
|
058
|
23724-AF
|
HOPPER BAG PIVOT ROD
|
N/A
|
POA
|
|
059
|
43407-AF
|
Bolt, Hex 3/8-16 x 3/4" Lg. * 43407
|
£3.91
|
Add
|
|
060
|
43082-AF
|
HEX LOCK NUT
|
£4.12
|
Add
|
|
061
|
1509-090
|
NO LONGER AVAILABLE
|
N/A
|
POA
|
|
062
|
714-0474
|
PIN (RED)
|
£3.20
|
Add
|
|
063
|
43978-AF
|
Bolt, Curved 1.4-20 x 1" 43978
|
£4.05
|
Add
|
|
064
|
23331-AF
|
THROTTLE CABLE CLIP 23331
|
£12.01
|
Add
|
|
065
|
23349-AF
|
DRAW BAR 23349
|
£32.20
|
Add
|
|
066
|
23354-AF
|
BAIL 23354
|
£11.94
|
Add
|
|
067
|
43001-AF
|
HEX BOLT (RED)
|
£3.49
|
Add
|
|
068
|
43062-AF
|
BOLT 3/8-16 X 1-1/2 HEX HEAD 43062
|
£4.99
|
Add
|
|
069
|
43082-AF
|
HEX LOCK NUT
|
£4.12
|
Add
|
|
070
|
R19172410-AF
|
WASHER-FLAT AF-R19172410
|
N/A
|
POA
|
|
071
|
43082-AF
|
HEX LOCK NUT
|
£4.12
|
Add
|
|
072
|
43070-AF
|
Washer, 3/8"
|
£3.91
|
Add
|
|
073
|
43087-AF
|
Hex Bolt, 3/8-16 x 1-1/4" Long 43087
|
£4.58
|
Add
|
|
074
|
44060-AF
|
RIVET 3/16 X 3/8 PLTD
|
£3.28
|
Add
|
|
075
|
43343-AF
|
PIN COTTER
|
£4.20
|
Add
|
|
076
|
23353-AF
|
HITCH PIN
|
£19.20
|
Add
|
|
077
|
23368-AF
|
Tube, Hitch Spacer 23368
|
£8.18
|
Add
|
|
078
|
43737-AF
|
Hopper Rope 43737
|
£5.99
|
Add
|
|
079
|
712-0158
|
NUT, HEX CENTER LOCK, 5/16-18
|
£9.35
|
Add
|
|
080
|
R19111116-AF
|
WASHER
|
£3.76
|
Add
|
|
081
|
62658-AF
|
WHEEL HANGER ASS'Y.-R.H.
|
£59.66
|
Add
|
|
082
|
62657-AF
|
WHEEL HANGER ASS'Y.-L.H.
|
£59.66
|
Add
|
|
083
|
44377-AF
|
Hex Bolt, 3/8-24 x 1" 44377
|
£4.05
|
Add
|
|
084
|
43086-AF
|
Lock Washer, 5/16" 43086
|
£3.48
|
Add
|
|
085
|
43910-AF
|
Washer, Flat #10 SAE 43910
|
£3.19
|
Add
|
|
086
|
44312-AF
|
SPROCKET GEAR
|
£27.06
|
Add
|
|
087
|
44006-AF
|
WASHER
|
£5.01
|
Add
|
|
088
|
44137-AF
|
Washer, Flat 1/2" I.D. 44137
|
£2.60
|
Add
|
|
089
|
43894-AF
|
STOPPING RING 43894
|
£3.76
|
Add
|
|
090
|
44319-AF
|
ROLLER CHAIN
|
£10.82
|
Add
|
|
091
|
44320-AF
|
WASHER .515 X .75 X .026
|
£3.70
|
Add
|
|
092
|
43659-AF
|
PIN, SPRING 3/16x1 AF-43659
|
£3.48
|
Add
|
