AGR08_0022B

Assembly drawing

Please use your mouse to zoom in and out for more detailed view

AGR08_0022B

Parts list

Match the number with the image on the left and click "Add" button to add the item to your basket

Please note, that the prices are for individual items

Items might appear more than once on the drawing, please check and adjust the quantity you require.

Ref No Description Price
48906 WHEEL £332.76 Add
44678-AF Spacer (45-0351) 44678 £14.07 Add
65408 WHEEL BEARING KIT £94.40 Add
48902 Owner's Manual N/A POA
001 25112 CART BODY £187.13 Add
002 23502-AF Tailgate 23502 £107.96 Add
003 62458-AF Tailgate Reinforcement Bracket 62458 £98.48 Add
004 23548-AF Tailgate Guide 23548 £11.15 Add
005 23492-AF Front Panel 23492 £96.74 Add
006 25106 WHEEL SUPPORT £151.92 Add
007 24497 Latch Stand Bracket N/A POA
008 24498 Latch Lock Lever N/A POA
009 23014-AF HITCH BRACKET £31.67 Add
010 25114 DRAW BAR TONGUE £97.69 Add
011 25107 AXLE £106.67 Add
012 23484-AF Front Corner Cap 23484 £21.81 Add
013 69599-AF WHEEL ASSY £257.23 Add
014 43093-AF COTTER PIN £3.11 Add
015 43601-AF WASHER £8.99 Add
016 731-0484A HUB CAP £5.05 Add
017 43866-AF Bolt, Hex 1/4-20 x 5/8" Lg. Gr. 5 43866 £3.48 Add
018 43343-AF PIN COTTER £4.20 Add
020 43814-AF SLOTTED TRUSS HEADBOLT(5/16-18x3/4) £3.11 Add
021 712-0429 NUT HEX.INS L NUT £4.92 Add
022 710-0514 HEX BOLT £3.81 Add
024 HA21362 NUT £3.96 Add
025 47408 Extension Spring N/A POA
026 47622 Spring Puller Tool N/A POA
027 47407-AF Hex Bolt, 5/16-18 x 3-3/4" * 47407 £4.20 Add
028 712-3004A HEX FLANGE NUT £2.97 Add
029 48948 Hitch Pin N/A POA
030 64873 Walking Beam (Includes #44488) £7.92 Add
032 46289 SPACER £5.31 Add
033 25111 Rail Brace N/A POA
034 44481-AF Cap, Vinyl 44481 £4.05 Add
035 44947-AF Bolt, Curved Head 5/16-18 x 1-5/8" 44947 £4.05 Add
038 43012-AF BOLT £3.32 Add
039 43088-AF FLAT WASHER £3.11 Add
040 47189-AF Hex Nylock Nut 1/4" 47189 £3.91 Add
041 46220-AF Washer, 1.03" x 1.38" x .120" (Thick) 1540-58 N/A POA
042 48949 Protective Edging Strip N/A POA
043 48951 Front Rail N/A POA
044 57-52631 Side Rail 48950 N/A POA
045 44488 Wheel Bearing (#43594 Wheel) N/A POA
046 43081-AF FLAT WASHER £3.49 Add
